FC Series Compound Switch

• Flameproof ATEX Exd Switch with an Adjustable Change Over Contacts (SPDT) or (DPDT)
• For Adjustable Switching Pressure Ranges Up to 400 bar.
• 1/4″ BSP Female Thread (Others Available)
• Stainless Steel Diaphragm (Others Available)
• Range -1 to +3.6 Bar
• Maximum working pressures up to 12 bar
• Black Epoxy powder coated die cast aluminium and all stainless steel enclosures.
• Flameproof EExd IIC T6 – ATEX & IECEx.
• SPDT or DPDT switching and optional gold alloy contacts.
• Optional wetted materials include – Monel, Titanium, Tantalum & Hastelloy C
• Terminal block for easy field wiring.
• Hermetically sealed microswitch options.
• 316 stainless steel wetted parts.
• NACE MR-01-75 compatibility – optional.

FC Compound Datasheet
