Adjustable Set Point
Our Adjustable Set Point collection offers a comprehensive selection of temperature switches designed to meet diverse industrial needs. From ORION, a trusted name in engineering solutions, these switches ensure precise temperature control in various environments.
- 25°C-215°C Set Points
- Max temperature up to 300°C
- Switch rating up to 250V
- 1/2” or 3/8” BSP thread(others available)
- 123mm Brass bulb,2m stainless capillary
- Visual scale optional
- Stainless steel sensing element membrane.
- Copper bulb and capillary.
- PN 10 Copper pocket with G ½ " connection.
- Base, cover and knob are in V0 self-extinguishing, antishock thermoplastic material.
- PVC grommet for cable entry.
- G ½ “ cable gland available on request
- 25°C-215°C Set Points
- Max temperature up to 300°C
- Switch rating up to 250V
- 1/2” or 3/8” BSP thread (others available)
- 123mm Brass bulb, 2m stainless capillary
- ATEX & IECEx approved
- 25°C-215°C Set Points
- Max temperature up to 300°C
- Switch rating up to 250V
- 1/2” or 3/8” BSP thread(others available)
- 123mm Brass bulb,2m stainless capillary
- Visual scale optional
