Temperature Switches, Sensors & Transducers
Introducing our comprehensive collection of Temperature Switches, Sensors & Transducers, meticulously designed to meet diverse industrial needs with precision and reliability.
EUROSWITCH Temperature Switches offer precise temperature control. Models like the Model 506 and Model 507 feature set points ranging from 25°C to 110°C and 35°C to 85°C, respectively. Constructed with durable brass (stainless steel options are available), these switches ensure robust performance with switch ratings up to 250V. ATEX options provide added safety in hazardous environments.
For adjustable temperature control, Pressure Vacuum Level's C03-C08 Adjustable Temperature Switch provides a wide range of 0°C to 200°C, with ±3°C calibration accuracy. Locking dial mechanisms enable secure setting of switch set-points, ensuring consistent performance in various applications.
ORION's MZ and MD, Adjustable Temperature Switches, offer versatility with set points ranging from 25°C to 215°C and switch ratings up to 250V. Visual scales and optional ATEX/IECEx approval enhance usability and safety.
HONSBERG's TF1 Temperature Switch boasts precise control with set points from 40°C to 120°C and a maximum temperature of 140°C, ideal for demanding environments. Brass or stainless steel construction ensures durability and reliability.
EUROSWITCH's EST Temperature Sensor delivers analogue output signals and operates within a wide temperature range (-20°C to +100°C). It features a robust AISI 316 case and IP65/IP67 protection.
For advanced functionality, Martens' MU125 and UT125 Temperature Transducers provide versatility in thermoelement and resistance measurements, with configurable outputs and easy installation on standard carrier rails.
Whether it's precise temperature control, reliable sensing, or versatile transduction, our collection offers solutions for efficient industrial operations. Trust in our products to deliver accuracy, durability, and performance excellence in every application.
- 25°C-110°C Set Points (5° increments)
- Max temperature 120°C
- Switch rating up to 250V
- 1/2” or 3/8” BSP thread(others available)
- Brass construction (stainless option)
- ATEX option available
- 35°C-85°C Set Points (5° increments)
- Max temperature 85°C
- Switch rating up to 250V
- 1/2” or 3/8” BSP thread(others available)
- Brass construction (stainless option)
- ATEX option available
- Stainless steel sensing element membrane.
- Copper bulb and capillary.
- PN 10 Copper pocket with G ½ " connection.
- Base, cover and knob are in V0 self-extinguishing, antishock thermoplastic material.
- PVC grommet for cable entry.
- G ½ “ cable gland available on request
- 25°C-215°C Set Points
- Max temperature up to 300°C
- Switch rating up to 250V
- 1/2” or 3/8” BSP thread(others available)
- 123mm Brass bulb,2m stainless capillary
- Visual scale optional
- Output signal: analogic 4-20mA
- Supply voltage: 8-30V
- Case: AISI 316
- Working temperature: -20 / +95° C
- Protection degree: IP65 / IP67
- Electrical connection: M12
- Max Torque: 50 Nm
- 25°C-215°C Set Points
- Max temperature up to 300°C
- Switch rating up to 250V
- 1/2” or 3/8” BSP thread (others available)
- 123mm Brass bulb, 2m stainless capillary
- ATEX & IECEx approved
- 25°C-180°C Set Points (5° increments)
- Max temperature 240°C
- Switch rating up to 240V
- Wide choice of threads
- Brass construction
- Rated to 300 bar
- 40°C-120°C Set Points (10° increments)
- Max temperature 140°C
- Switch rating up to 250V
- 1/2” or 3/4” BSP thread
- Brass or stainless construction
- Rated to 100 bar
- Output signal: IO-Link
- Supply voltage: 24±10%
- Case: AISI 316
- Working temperature: -20 / +95° C
- Protection degree: IP65 / IP67
- Electrical connection: M12
- 25°C-215°C Set Points
- Max temperature up to 300°C
- Switch rating up to 250V
- 1/2” or 3/8” BSP thread(others available)
- 123mm Brass bulb,2m stainless capillary
- Visual scale optional
- Up to 170°C Set Points
- Max temperature 210°C
- Switch rating up to 250V
- Die Cast Aluminium
- ± 3°C Tolerance
- Thermoelements J, K, S
- Pt100 / Pt1000 / NTC resistance measurement
- 4..20 mA analogue output
- Universal input for Pt100, Pt1000, thermocouple, NTC and resistance measurement value
- Configuration via front DIP switches
- Analog actual value output 4 .. 20mA
- Zero point and limit value can be adjusted via trim potentiometers on the front
- Wide-range mains adapter or 24 V DCa
- Optional supply via carrier rail bus
- Removable coded screw terminals or optional push-in terminals
- Housing width 12.5 mm
- Carrier rail mounting TS35 EN60715
- Thermoelements J, K, S
- Pt100 Elements
- 0/2..10 V und 0/4..20 mA
- 4..20 mA analogue output
- Transmitter for electrical signals
- Universal input for standard signals, Pt100, thermocouple, potentiometer
- Configuration via front-side DIP switch
- Wide-range power supply or 24 V DC
- Housing width 12.5 mm
- Removal coded screw terminals
- Carrier rail mounting TS35 EN60715
