Model 82 Electrical Differential Pressure Indicator with Rotating System

  • Medium: Oil - Air
  • Case: Brass Electric contact:
  • Silver Max fluid temperature: 100°C - UL/CSA version 85°C
  • Electrical conditions: SPDT (exchange contact)
  • Max working pressure: 450 bar 350 bar depending on the thread
  • Thread: 1/2” Gas standard (others on request)
  • Tightening torque: 50-70 Nm
  • Protection degree: IP65 with connector according to UNI EN 175301-803 (DIN43650)
  • Approx. weight ~ 160 g

Technical Datasheet
£0.00 In Stock Sold out
Looking for a dependable differential pressure indicator? Look no further than our Model 82. It features an 8-bar max working pressure and SPDT change-over switching contacts. Plus, the brass case ensures durability.
.
