Valvulas
Floating Valve SS A.304
- Made from stainless steel
- Swing type valve with silicone shutter
- Available in Viton, EPDM, Buna, PTFE
- Connection with Gas thread cylindrical DIN – ISO 228/1985.
- Nominal pressure PN – 10, maximum variable pressure 10 bar
- Description
- Downloads
Description
Made from stainless steel 18/8 (AISI – 304/DIN 1.4301) and 18/8/2 (AISI 316/DIN 1.4401), With a black polythene cover, polythene buoys available in stainless steel AISI – 304/AISI – 316 on demand.
Swing type valve with silicone shutter, available in Viton, EPDM, Buna, PTFE, etc., on demand.
The valve closes progressively. Valve system patented and guarantees a perfect seal with minimum force from the float. Connection with Gas thread cylindrical DIN – ISO 228/1985. Nominal pressure PN – 10, maximum variable pressure 10 bar
Downloads
