Fig 200 B Float Valve
- AISI 316 Stainless Construction
- PN16/10 Flange Connection DIN 2576. Optional ANSL 150LB
- Total Step - Silicone Closure. Pn-16
- Maximum Pressure 10 bar
- Description
- Downloads
Introducing our innovative valve system, featuring a patented design that ensures a flawless seal with minimal force exerted by the float. This valve system guarantees durability and longevity and is made from high-quality stainless steel 18/8 (AISI 316 / DIN 1.4401 & CF8M, DIN 1.4408).
The swing-type valve is equipped with a silicone shutter, available in VITON, EPDM, BUNA, PTEF, and other options upon request, providing versatility to suit various applications. Notably, the valve closes progressively, enhancing control and precision in fluid regulation.
Designed to meet the demands of challenging environments, our valve system is particularly effective for turbulent waters and areas prone to water deposits, such as refrigeration towers. In such conditions, reinforced levers are recommended for optimal performance.
With a nominal pressure of PN-16 and a maximum variable pressure of 10 bar, our valve system is engineered to deliver reliable results under diverse operating conditions.
