FC Series Vacuum Switch
FC Series Vacuum Switch

FC Series Vacuum Switch

  • Working pressure up to 12 bar
  • SPDT or DPDT switching
  • Reliable, accurate micro switches
  • 1/4” BSP thread (others available)
  • 316 stainless steel wetted parts
  • ATEX Exd IIC T6 level of certification
£0.00 In Stock Sold out
  • Flameproof ATEX Exd Switch with an Adjustable Change Over Contacts (SPDT) or (DPDT)
  • For Adjustable Switching Pressure Ranges Up to 400 bar.
  • 1/4″ BSP Female Thread (Others Available)
  • Stainless Steel Diaphragm (Others Available)
  • Ranges available up to -760 -to 100mm Hg (-1 to 0 Bar)
  • Maximum working pressures up to 12 bar
  • Black Epoxy powder coated die cast aluminium and all stainless steel enclosures.
  • Flameproof EExd IIC T6 – ATEX & IECEx.
  • SPDT or DPDT switching and optional gold alloy contacts.
  • Optional wetted materials include – Monel, Titanium, Tantalum & Hastelloy C
  • Terminal block for easy field wiring.
  • Hermetically sealed microswitch options.
  • 316 stainless steel wetted parts.
  • NACE MR-01-75 compatibility – optional.
