WR 302 - 3 Piece Full Bore Ball Valve
- Construction: stainless steel. CF8M (316) investment casting.
- Gas threaded ends DIN 2999.BSP
- Seats and seals : PTFE + 15% GF o’ring stem: viton . PN 63
- Temp: -25°+ 180°C.
- Direct assembling ISO 5211 with locking system.
- Description
- Downloads
The WR 302 is a premium 3-piece full bore ball valve designed for reliable and high-performance fluid control. Constructed from CF8M (316) stainless steel using investment casting, this valve offers exceptional durability and corrosion resistance, making it suitable for demanding applications. It features gas threaded ends (DIN 2999 BSP) and PTFE seats reinforced with 15% glass fibre for added strength and longevity. The stem is sealed with a Viton O-ring to ensure leak-free operation under pressure.
With a pressure rating of PN 63 and an operating temperature range of -25°C to +180°C, the WR 302 is ideal for industrial, chemical, and general-purpose use. The valve includes a direct ISO 5211 mounting pad with a locking system for secure and easy actuator installation. Its modular three-piece design allows for simple maintenance and cleaning, making it a reliable and cost-effective solution for fluid handling systems.
