Differential Pressure Transmitter / Switch OMNI-DP2

Differential pressure measurement for non-aggressive gases
Short reaction time
Analog output, two switching outputs
Clear, easily legible, illuminated LCD display
Designed for industrial use
Small, compact construction
Very simple installation
Control panel assembly (IP65)

Description
Downloads
Product Catalogue

Description

The sensor measures the difference of the pressures at the two pressure ports P1 and P2 by means of piezo-resistive pressure sensor elements on a ceramic substrate. The sensors are compensated in the entire operating temperature range and offer excellent drift and long+term stability. The pressure ports are designed as hose connections with a 3 mm outside diameter.
