MP Multipulse Flowmeter
- Nominal sizes of 15mm to 50mm
- 0.2 - 330 l/min flow ranges
- Aluminium, 316 stainless or UPVC
- -40 to 100 °C temperature ranges
- Quadrature pulse output option
- Ideal for visocus fluids
- Description
- Downloads
The MP Multipulse Flowmeter delivers exceptional accuracy and reliability in flow monitoring, control, and batching applications. Engineered for high performance, these positive displacement flowmeters are ideal for clean liquids, including viscous lubricants, chemicals, food bases, and non-conductive solvents—whether pumped or gravity-fed. With flow capacities from 0.2 to 330 litres/min and connection sizes from 15mm to 50mm (½" to 2"), they offer direct-reading accuracy up to ±0.2% with optional correction and repeatability of ±0.03%.
No straight pipe runs are needed, making installation flexible. Intrinsically safe and explosion-proof models are available, with output options including quadrature pulse and bi-directional flow. Housed in durable materials like aluminium, stainless steel, and UPVC, the [MP] series supports a wide range of temperatures (–40°C to +200°C) and pressures (up to 350 bar). A trusted choice for demanding environments.
