KM-A Flow Limiter
- Metal inserts up to 210 l/min.
- Media temperature up to 200°C
- Nominal widths DN 32 to DN 80
- Brass/stainless steel materials
- Male thread Installation location as desired
- No need for auxiliary power
- Description
- Downloads
The Honsberg KM-A Flow Limiter is a highly reliable, passive flow control device designed to maintain a constant flow rate regardless of pressure fluctuations. Using an innovative mechanical design, the limiter features two stainless steel spring plates that adjust an annular gap to regulate flow—delivering consistent performance without the need for auxiliary power.
With flow capacities of up to 210 litres per minute, the KM-A is suitable for a wide range of industrial applications, including heating and cooling systems, water distribution, and process engineering. It supports media temperatures up to 200°C, and is available in nominal widths from DN 32 to DN 80, offering versatility across multiple system types.
Constructed from brass or stainless steel, and designed with male threaded connections, the KM-A is easy to install in any orientation, even in tight spaces. Its durable design ensures long-term, maintenance-free operation.
